Mitsubishi M80 series User Manual

M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
23
IB-1501269-J
3.18 MITSUBISHI CNC Machine Operation Panel [E80]
3.19 Handy Terminal
3.20 Cable Connector Sets
Classification Type Components Remarks
Main panel A
(For 8.4-type/15-type display unit)
FCU8-KB922
Escutcheon, key switch
control card
G054 cable, Screw cap set
Custom specification key layout (55 keys)
(Clear key top cover sold separately)
Main panel A
(For 8.4-type/15-type display unit)
FCU8-KB925
Escutcheon, key switch
control card
G054 cable, Screw cap set
MITSUBISHI standard key layout (55 keys)
(Standard specification B)
Sub panel A
(Common for all display units)
FCU8-KB941
Escutcheon
Emergency stop switch, Override switch
ON/OFF switch, Screw cap set
MITSUBISHI standard switch specification
(Standard specification B)
Clear key top set
N030C975G51 /
N030C975G55
Clear key top cover (20 pcs/60 pcs)
Set of labels for M7 standard key layout N939A169G51
Labels for M7 standard key layout (1
sheet)
Classification Type Components Remarks
Handy Terminal
HG1T-SB12UH-
MK1346-L5
Classification Type Components Remarks
General I/O units
(For SKIP,SIO,MPG,AIO)
FCUA-CS000
Connector (10120-3000PE,2pcs),
Shell kit (10320-52F0-008,2pcs)
Emergency stop connector
(For EMG)
005057-9403
0016020103 x 3 pcs.
Connector (50-57-9403),
Contact (0016020103,3pcs.)
Connector kit for RIO 2.0 unit RIO2 CON
Connector (1-1318119-3,2pcs.),
Contact (1318107-1,8pcs.),
Connector (2-178288-3),
Contact (1-175218-5,3pcs)
24VDC power supply connector
(For DCIN)
FCUA-CN220
Connector (2-178288-3),
Contact (1-175218-5,3pcs)
DI/DO connector
(For operation panel I/O unit)
(For remote I/O unit)
7940-6500SC x
4pcs.
3448-7940 x 4pcs.
Connector (7940-6500SC,4pcs.),
Strain relief (3448-7940,4pcs.)
FCU8-DX731
DI connector (For operation panel I/O
unit)
7950-6500SC x
2pcs.
3448-7950 x 2pcs.
Connector (7950-6500SC,2pcs.),
Strain relief (3448-7950,2pcs.)
FCU8-DX750/760/761
Connector for CJ71
2-1318119-4
1318107-1 x 8pcs.
Connector (2-1318119-4),
Contact (1318107-1,8pcs.)
THERMISTOR connector
37104-2165-000FL
10P
Connector (37104-2165-000FL,10pcs.)
