M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
26
IB-1501269-J
[Cable Relating to Drive Unit]
(Note 1) "x" in type columns indicate cable length (unit: m).
(Note 2) Lengths indicated with an asterisk (*) in the max. cable length column indicate the maximum cable length
when connecting via other unit.
3.26 System Type
Type Application Available cable length (m)
Max. cable
length
CNP2E-1-xM
Motor side PLG cable
Spindle side accuracy encoder
TS5690 cable
2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
CNP3EZ-2P-xM
Spindle side encoder cable
OSE-1024 cable
2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
CNP3EZ-3P-xM
Spindle side encoder cable
OSE-1024 cable
2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
CNV2E-8P-xM For HG/HG-H,HQ/HQ-H Motor side encoder cable (for D48/D51/D74) 2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
CNV2E-9P-xM For HG/HG-H,HQ/HQ-H Motor side encoder cable (for D48/D51/D74) 2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
CNV2E-D-xM MDS-B-SD unit cable 2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
CNV2E-HP-xM MDS-B-HR unit cable 2, 3, 4, 5, 7, 10, 15, 20, 25, 30 30m
DG30-xM
Battery cable
(For drive unit - Battery box,
For drive unit - drive unit)
0.3, 0.5, 1, 2, 3, 5, 7, 10 10m
G380 LxM
Optical communication cable
For wiring between drive units (outside panel)
5, 10, 12, 15, 20, 25, 30 30m
J395 LxM
Optical communication cable
For wiring between drive units (outside panel)
For wiring between NC-drive units
3, 5, 7, 10 10m
J396 LxM
Optical communication cable
For wiring between drive units (inside panel)
0.2, 0.3, 0.5, 1, 2, 3, 5 10m
MR-
BKS1CBLxMA1-H
<200V Series>
Brake cable for HG96
Lead out in direction of motor shaft
2, 3, 5, 7, 10 10m
MR-
BKS1CBLxMA2-H
<200V Series>
Brake cable for HG96
Lead out in opposite direction of motor shaft
2, 3, 5, 7, 10 10m
MR-BT6V2CBL
LxM
Battery cable (MDS-EJ/EJH)
(For drive unit - drive unit)
0.3, 1 1m
MR-D05UDL3M-B STO cable 3 3m
MR-
PWS1CBLxMA1-H
<200V Series>
Power cable for HG96
Lead out in direction of motor shaft
2, 3, 5, 7, 10 10m
MR-
PWS1CBLxMA2-H
<200V Series>
Power cable for HG96
Lead out in opposite direction of motor shaft
2, 3, 5, 7, 10 10m
SH21 LxM
Power supply communication cable
Power backup unit communication cable
0.35, 0.5, 1, 2, 3 30m
Series Model name System type Control unit Display unit
M800S Series
M850S
FCA850H-8S
FCU8-MA542-001
FCU8-DU181-31 (15-type color LCD touchscreen)
FCA850H-4S FCU8-DU141-31 (10.4-type color LCD touchscreen)
M830S
FCA830H-8S
FCU8-MU542-001
FCU8-DU181-31 (15-type color LCD touchscreen)
FCA830H-4S FCU8-DU141-31 (10.4-type color LCD touchscreen)
M80 Series
M80 TypeA
FCA80H-8A
FCU8-MU512-001
FCU8-DU181-32 (15-type color LCD touchscreen)
FCA80H-4A FCU8-DU141-32 (10.4-type color LCD touchscreen)
FCA80P-2A FCU8-DU121-12 (8.4-type color LCD)
M80 TypeB
FCA80H-8B
FCU8-MU511-001
FCU8-DU181-32 (15-type color LCD touchscreen)
FCA80H-4B FCU8-DU141-32 (10.4-type color LCD touchscreen)
FCA80P-2B FCU8-DU121-12 (8.4-type color LCD)
E80 Series
E80 TypeA FCA80P-2EA FCU8-MU514-001 FCU8-DU121-13 (8.4-type color LCD)
E80 TypeB FCA80P-2EB FCU8-MU513-001 FCU8-DU121-13 (8.4-type color LCD)
