M800S/M80/E80 Series Connection and Setup Manual
29 Setting the Deceleration Check
535
IB-1501269-J
29.4 Parameter
(1) Designating deceleration check
Base specification parameter
(2) Deceleration check during opposite direction travel
Base specification parameter
# Item Details Setting range
1193 inpos
The definitions are changed with the setting of "#1306 InpsTyp
Deceleration check specification type".
When
Deceleration
check method 1 is
selected
Select the deceleration check method for G0.
0: Command deceleration check
1: In-position check
2: Smoothing check
0 to 2
When
Deceleration
check method 2 is
selected
Select the deceleration confirmation method for the
positioning or cutting command.
0: G0, G1+G9 Command deceleration check
1: G0, G1+G9 In-position check
2: G0,G1+G9 Smoothing check
1223 aux07/bit1
Deceleration
check method 2
Select the deceleration check method in G1+G9.
0: Command deceleration check in G1+G9
1: In-position check in G1+G9
The deceleration check is not performed for the
commands except G1+G9.
When "#1306 InpsTyp deceleration check
specification type" is set to "1" (Deceleration check
specification type 2), this parameter will be invalid.
0 / 1
1306 InpsTyp
Deceleration
check
specification type
Select the parameter specification type for the G0 or
G1 deceleration check.
0: Deceleration check specification type 1
G0 is specified with "#1193 inpos",
and G1+G9 with "#1223 aux07/bit1".
1: Deceleration check specification type 2
G0 or G1+G9 is specified with "#1193 inpos".
0 / 1
1389 G1SmthChk
Smoothing check
method in cutting
block
Select whether to apply smoothing check method to a
cutting block for deceleration check, when
deceleration check method is selected individually for
G0 and G1 (when #1306 InpsTyp=1).
0: Follow the setting of Aux07/BIT1
1: Apply smoothing check method
0 / 1
# Item Details Setting range
1502 G0Ipfg
G1 -> G0
deceleration
check
Select whether to perform a deceleration check when the
travel direction is changed from G1 to G0.
0: Not perform
1: Perform
0 / 1
1503 G1Ipfg
G1 -> G1
deceleration
check
Select whether to perform a deceleration check when the
travel direction is changed from G1 to G1.
0: Not perform
1: Perform
0 / 1
