M800S/M80/E80 Series Connection and Setup Manual
15 Cable
371
IB-1501269-J
15.3.13 MR-D05UDL3M-B Cable
Max. cable length: 3m
Application: STO cable
15.3.14 MR-PWS1CBL-A1-H / MR-PWS1CBL-A2-H Cable
Max. cable length: 10m
Application: <200V Series> Power cable for HG96
MR-PWS1CBL-A1-H (load side angle)
MR-PWS1CBL-A2-H (reverse load side angle)
<Cable connection diagram>
4
5
3
6
7
8
CN8
STO1
STO2
STOCOM
24G
24V
TOF1
TOF2
TOFCOM
STO1 input
STO2 input
Drive unit side
(Tyco Electronics)
Connector set:
MR-D05UDL3M-B
TOF1 output
TOF2 output
Yellow (Dot mark: Red)
Gray (Dot mark: Black)
Yellow (Dot mark: Black)
Gray (Dot mark: Red)
White (Dot mark: Black)
White (Dot mark: Red)
U
V
W
Servo motor power supply connector
(Japan Aviation Electronics)
Connector: JN4FT04SJ1-R
Hood, Socket insulator,
Bushing and Grand nut
Contact: ST-TMH-S-C1B-100(A534G)
Crimp tool: CT160-3TM5B
AWG 19 (Red)
AWG 19 (White)
AWG 19 (Black)
AWG 19 (Green/ Yellow)
