M800S/M80/E80 Series Connection and Setup Manual
4 General Specifications
28
IB-1501269-J
4.1 Environment Conditions [M800S]
4.1.1 Installation Environment Conditions
(Note 1) "Short term" means roughly within one month.
(Note 2) The current consumption of the display unit is included in that of the control unit.
(Note 3) For the whole NC system, consider the characteristics of the drive units when the altitude is more than 1000
meters above sea level. Refer to the manual of drive unit for details.
(Note 4) When the display unit is mounted on an incline, the inclination angle to place the unit should be 30 degrees or
less from the vertical direction.
Item
Unit name Control unit Display unit
Type
FCU8-MU542/MA542
FCU8-MU541/MA541
FCU8-DU141-31 : (10.4-type)
FCU8-DU181-31 : (15-type)
General
Specifications
Ambient
temperature
During
operation
0 to 58°C
During
storage
-20 to 60°C
Ambient
humidity
Long term 10 to 75% RH (with no dew condensation)
Short term 10 to 95% RH (with no dew condensation) (Note 1)
Vibration resistance
4.9m/s
2
or less
Shock resistance
29.4m/s
2
or less
Working atmosphere No corrosive gases, dust or oil mist
Altitude
Operation/Storage: 1000 meters or less above sea level,
Transportation: 13000 meters or less above sea level
Power supply voltage 24VDC
FCU8-DU141-31 : 12VDC/5VDC/3.3VDC
FCU8-DU181-31 : 12VDC/5VDC/3.3VDC
(Supply from Control Unit)
Current consumption 24V 2.5A - (Note 2)
Maximum
heating value
(W) 16
FCU8-DU141-31 : 10
FCU8-DU181-31 : 14
Mass (kg) 1.1
FCU8-DU141-31 : 1.7
FCU8-DU181-31 : 4
Outline
dimension
W×H×D
or
W×H
(mm) 239.1×173.4×75
FCU8-DU141-31 : 290×220
FCU8-DU181-31 : 400×320
