M800S/M80/E80 Series Connection and Setup Manual
9 Connection of Operation Panel I/O Unit
276
IB-1501269-J
9.8.3 Wiring for Source Type Output
[FCU8-DX731]
For connection details, refer to the descriptions on machine input connector pin assignment in "(2) Machine signal output
(CG32)" and "(6) Machine signal output (CG36)" of "General Specifications: Operation Panel I/O Unit".
CG36
B20
B19
B18
B17
B16
B15
B14
B13
B12
B11
B10
B09
B08
B07
B06
B05
Y240
Y241
Y242
Y243
Y244
Y245
Y246
Y247
Y248
Y249
Y24A
Y24B
Y24C
Y24D
Y24E
Y24F
FCU8-DX731
0V
FG
A20
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A09
A08
A07
A06
A05
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
NC
B04
B03
B02
B01
A04
A03
A02
A01
DOCOM
DOCOM
DOCOM
DOCOM
DOCOM
DOCOM
0V
0V
CG32
B20
B19
B18
B17
B16
B15
B14
B13
B12
B11
B10
B09
B08
B07
B06
B05
Y200
Y201
Y202
Y203
Y204
Y205
Y206
Y207
Y208
Y209
Y20A
Y20B
Y20C
Y20D
Y20E
Y20F
FCU8-DX731
0V
FG
A20
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A09
A08
A07
A06
A05
Y210
Y211
Y212
Y213
Y214
Y215
Y216
Y217
Y218
Y219
Y21A
Y21B
Y21C
Y21D
Y21E
Y21F
B04
B03
B02
B01
A04
A03
A02
A01
DOCOM
DOCOM
DOCOM
DOCOM
DOCOM
DOCOM
0V
0V
24VDC(+)
Machine sideMachine side
Stabilized
power supply
24VDC(+)
Stabilized
power supply
