M800S/M80/E80 Series Connection and Setup Manual
3 List of Configuration
20
IB-1501269-J
3.11 Remote I/O Unit [M800S/M80]
(Note) DI: Digital input signals, DO: Digital output signals, AI: Analog input signals, AO: Analog output signals
Classification Type Components Remarks
DI 24V/0V common input [32 points]
DO Source output [32 points]
FCU8-DX220
Base card
RIO 2.0 connector set
DI: 32-points 24V/0V common type
Do: 32-points source type (200mA/point)
Number of occupied stations: 1
DI 24V/0V common input [64 points]
DO Source output [48 points]
FCU8-DX230
Base card
RIO 2.0 connector set
DI: 64-points 24V/0V common type
DO: 48-points source type (200mA/point)
Number of occupied stations: 2
DI 24V/0V common input
DO Source output [48 points]
AO Analog output [1 point]
FCU8-DX231
Base card
RIO 2.0 connector set
DI: 64-points 24V/0V common type
DO: 48-points source type (200mA/point)
AO: 1 point
Number of occupied stations: 2
AI Analog input [4 points]
AO Analog output [1 point]
FCU8-DX202
Base card
RIO 2.0 connector set
AI : 4 points
AO: 1 point
Number of occupied stations: 1
DI 0V common input [16 points]
DO Source output (large capacity) [8
points]
FCU8-DX213
Base card
RIO 2.0 connector set
DI: 16-points 0V common type (3mA/point)
DO: 8-points source type (2A/point)
Number of occupied stations: 1
DI 0V common input [16 points]
DO Source output (large capacity) [8
points]
FCU8-DX213-1
Base card
RIO 2.0 connector set
DI: 16-points 0V common type (9mA/point)
DO: 8-points source type (2A/point)
Number of occupied stations: 1
Safety DI 0V common input [8 points]
Safety DO Source output (large capacity)
[4 points]
FCU8-DX654
Base card
RIO 2.0 connector set
Safety DI: 8-points 0V common type (3mA/point)
Safety DO: 4-points source type (2A/point)
Number of occupied stations: 2
Safety DI 0V common input [8 points]
Safety DO Source output (large capacity)
[4 points]
FCU8-DX654-1
Base card
RIO 2.0 connector set
Safety DI: 8-points 0V common type (9mA/point)
Safety DO: 4-points source type (2A/point)
Number of occupied stations: 2
DI 24V/0V common input [32points]
DO Source output [32 points]
Safety DI 0V common input [8 points]
(Note 1)
Safety relay output [4 points] (Note 2)
FCU8-DX651
Base card
Add-on card
RIO 2.0 connector set
DI: 32-points 24V/0V common type
Do: 32-points source type (200mA/point)
Safety DI: 8-points 0V common type
Safety relay: 4-points (non-voltage contact)
Relay contact welding detection
Number of occupied stations: 3
(Note 1) Safety DI uses 16 points of terminal
because of the duplication wiring.
(Note 2) Safety relay output uses 8 points of
terminal because of the duplication wiring.
Thermistor input [12 points] FCU8-DX408
Base card
RIO 2.0 connector set
Thermistor input: 12 points
Number of occupied stations: 3
Multi-analog input [4 points] (Note 3) FCU8-DX409
Base card
RIO 2.0 connector set
Multi-analog input: 4 points
(Note 3) Voltage input, current input,
thermocouple input and resistance temperature
detector input are selected for each CH.
Number of occupied stations: 4
