Mitsubishi M80 series User Manual

M800S/M80/E80 Series Connection and Setup Manual
9 Connection of Operation Panel I/O Unit
281
IB-1501269-J
9.8.6 Connection with the scan output signal (FCU8-DX834)
For connection details, refer to the descriptions on machine output connector pin assignment in "(19) OPKB (Scan input,
Scan output)" of "General Specifications: Operation Panel I/O Unit".
Y240Y241Y242Y243Y244Y245Y246Y247
Y248Y249Y24AY24BY24CY24DY24EY24F
LC0A
LC1A
LC2A
LC3A
LD0A*
LD1A*
LD2A*
Y250Y251Y252Y253Y254Y255Y256Y257
Y258Y259Y25AY25BY25CY25DY25EY25F
LD3A*
LD4A*
LD5A*
LD6A*
LD7A*
Y260Y261Y262Y263Y264Y265Y266Y267
Y268Y269Y26AY26BY26CY26DY26EY26F
LC0B
LC1B
LC2B
LC3B
LD0B*
LD1B*
LD2B*
Y270Y271Y272Y273Y274Y275Y276Y277
Y278Y279Y27AY27BY27CY27DY27EY27F
LD3B*
LD4B*
LD5B*
LD6B*
LD7B*
OPKB
A21
A22
A23
A24
A13
A14
A15
A16
A17
A18
A19
A20
B21
B22
B23
B24
B13
B14
B15
B16
B17
B18
B19
B20
FCU8-DX834
Machine side
