M800S/M80/E80 Series Connection and Setup Manual
29 Setting the Deceleration Check
531
IB-1501269-J
(b) Selecting the deceleration check method
There are three methods for the deceleration check, and the method is selected by the parameter.
1) For the execution block with the rapid traverse command (G00/G53)
2) For the execution block with the cutting feed command (G01/G02/G03)
When the parameter "#1306 InpsTyp" is "1", the deceleration check method will be the same as the method of
1) rapid traverse regardless of the value of the parameter "#1389 G1SmthChk".
Parameter
Deceleration check method Determination condition
#1193 inpos
0 Command deceleration check
Deceleration check time
passed
1 In-position check method
Deceleration check time
passed,
all axis smoothing zero
and all axis in-position
2 Smoothing check method
Deceleration check time
passed
and all axis smoothing zero
Parameter
Deceleration check method Determination condition
#1306 InpsTyp
(G0/G1 common)
#1389
G1SmthChk
#1223
aux07/BIT1
0
(cutting block)
0
0 Command deceleration check
Deceleration check time
passed
1 In-position check method
Deceleration check time
passed,
all axis smoothing zero
and all axis in-position
1-Smoothing check method
Deceleration check time
passed
and all axis smoothing zero
