[Note]
(1) When the restoration fails, perform the restoration again otherwise it may cause an abnormal operation.
(2) Restored data writes over the previous absolute position data. Carry out the absolute position detection again after
restoration.
(5) Move the cursor to select the file. Press the
[INPUT] key.
The operation message "OK? (Y/N)" appears.
The cursor moves as follows:
[ ↓ ] key:
Auto1 -> Auto2 -> Auto3 -> Manual -> Auto1 ...
[ ↑ ] key:
Auto1 -> Manual -> Auto3 -> Auto2 -> Auto1-> ...
<Note>
- If there are no files at the position where the cursor moved
to, the operation message "Select directory to restore"
appears. Select the file again and then press the [INPUT]
key.
(6) Press [Y], [y] or [Input]. The restoration starts. "Executing" and "*" are
displayed for the state of file under processing.
<Note>
- If PLC is in operation, the "PLC running. Does it stop? (Y/
N)" message is displayed. Press [Y], [y] or [INPUT] to
continue the restoration.
- If the tool data is being sorted, the operation message
"File access error" is displayed and the restoration cannot
be executed.
- For the custom data, the restoration cannot be canceled
during its execution.
(7) The restoration is completed without error. The states of restoration-complete files turn to
"Complete", the operation message "Restore
complete" appears.
"Unexecute" is displayed for the file which could not be
restored, for instance, due to the nonexistence of the
file.
To Next Page
