R01UH0823EJ0100 Rev.1.00 Page 1804 of 1823

Jul 31, 2019

RX23W Group 51. Electrical Characteristics

Figure 51.61 Comparator Output Delay Time in Comparator High-Speed Mode and Low-Speed Mode

Figure 51.62 Comparator Output Delay Time in High-Speed Mode with Window Function Enabled

CMPB

CMPOB

td td

CVREFB = 0 V

CMPB

CMPOB

tdw tdw

Internal vrh = VCC * 0.76

CMPB

CMPOB

tdw tdw

Internal vrh = VCC * 0.24
