Browser Unit Type D (D377)
SM 1-83 D017/D018/D019/D020
Installation
1.22 BROWSER UNIT TYPE D (D377)
1.22.1 ACCESSORIES
Check the accessories and their quantities against the table below.
Description Qt'y
1. Browser Unit D377 SD Card 1
1.22.2 INSTALLATION
This option requires a HDD unit.
1. Switch the machine off.
2. Remove the plastic application cover [A] ( x1).
3. Insert the browser SD card [B] into SD card Slot 1
(upper).
4. Turn the machine on.
5. Push [User Tools]> [Login/Logout].
6. Login with the administrator user name and
password.
7. Touch "Extended Feature Settings" twice.
8. Touch "SD Card" then touch the "Browser" line.
9. Under "Install to:" touch "Machine HDD"> "Next".
10. When you see "Ready to Install", check the
information on the screen to confirm your previous selection.
11. Touch "OK". You will see "Installing…" then "Completed".
12. Touch "Exit" twice to return to the copy screen.
13. Remove the SD card from the SD card slot.
To Next Page
