Transfer Unit
SM 3-31 D017/D018/D019/D020
Replacement
and
Adjustment
3.6 TRANSFER UNIT
 Turn off the main power switch and disconnect the power cord before you start any
of the procedures in this section.
3.6.1 TRANSFER ROLLER UNIT
1. Open the right cover [A].
2. Remove the transfer roller unit [B] (Hook x1).
 Do not touch the transfer roller surface.
To Next Page
