Copy Adjustments: Printing/Scanning
SM 3-61 D017/D018/D019/D020
Replacement
and
Adjustment
3.10 COPY ADJUSTMENTS: PRINTING/SCANNING
You must do these adjustment(s) after replacing any of the following parts:
 Scanner Wire
 Lens Block/SBU Assembly
 Scanner Drive Motor
 Polygon Mirror Motor
 Paper Side Fence
 Memory All Clear
For more details about accessing SP modes, see Service Tables.
3.10.1 PRINTING
 Make sure the paper is installed correctly in each paper tray before you start these
adjustments.
 Use the Trimming Area Pattern (SP2-902, No.10) to print the test pattern for the
following procedures.
 Set SP 2-902 to 0 again after completing these printing adjustments.
Registration - Leading Edge/Side-to-Side
1. Check the leading edge registration for each paper feed station, and adjust them using
SP1-001.
2. Check the side-to-side registration for each paper feed station, and adjust them using
SP1-002.
Tray SP mode Specification
Any paper tray SP1-001-1
By-pass feed SP1-001-2
Duplex SP1-001-3
3 ± 2 mm
1st paper feed SP1-002-1
2nd paper feed SP1-002-2
3rd paper feed (Optional SP1-002-3
2 ±1.5 mm
To Next Page
