Fax Unit Configuration
D361 190
SM
6.5
FAX UNIT CONFIGURATION
Component
Code
No.
Remarks
FCU 6
MBU 7
S
peaker
D361
1
Included with fax unit
CCU I/F Board
3
G3 Board
D361
4
Included with optional G3 unit.
G3 Board
D361
5
Included with optional G3 unit.
Expansion Memory
G578
2
Common with R-C4/4.5
Handset T
ype 1018
B433
USA
only
. Common with R-C4/4.5
923
925
