Installation Requirements
D017/D018/D019/D020 1-2 SM
A: In Front: Over 750 mm (29.6"), B: Left: Over 100 mm (0.4")
C: To Rear: Over 100 mm (0.4"), D: Right: Over 100 mm (0.4")
E: 640 mm (25.2"), F: 550 mm (21.7"), G: 1137 mm (44.8")
 The 750 mm recommended for the space at the front is only for pulling out the
paper tray. If an operator stands at the front of the copier, more space is required.
1.1.4 POWER REQUIREMENTS
 Make sure that the wall outlet is near the copier and easily accessible.
 Make sure the plug is firmly inserted in the outlet.
 Avoid multi-wiring.
 Be sure to ground the machine.
1. Input voltage level
 120 V, 60 Hz: More than 12 A
 220 V to 240 V, 50 Hz/60 Hz: More than 7 A
 110V, 50 Hz/60 Hz: More than 13 A
2. Permissible voltage fluctuation: 10 %
3. Do not set anything on the power cord.
