Specifications
SM 7-3 D017/D018/D019/D020
Specifications
Maximum (w x d) With Side Finisher, Bypass
858 x 653 mm
(33.8 x 25.7 in.)
Full System All Options
1165 x 653 x 1100 mm
(48.9 x 25.7 x 43.3 in.)
No Duplexer Less than 60 kg (132 lb)
Weight
With Duplexer Less than 65 kg (143 lb)
Noise Emission (Sound Power Level):
Stand-by (Mainframe only): 40 db
Operating (Mainframe only):
64.8 db (D017/D019)
67.6 db (D018/D020)
 The above measurements were made in accordance with ISO 7779.
 Full System: Mainframe + ADF + 1-bin Sorter + Paper Tray Unit + Duplex Unit +
Bridge Unit + Finisher
7.1.2 OPTIONS
ARDF (D366)
Size A3 to A5, DLT to HLT
Simplex
Weight 40 to 128 g/m
2
(10 to 34 lb)
Size A3 to A5, DLT to HLT
Paper Size/Weight:
Duplex
Weight 52 to 105 g/m
2
(14 to 28 lb)
Table Capacity: 50 sheets (80 g/m
2
, 20 lb)
Original Standard Position: Rear left corner
Separation: Feed belt and separation roller
