Key Counter Bracket Type M3
Accessory Check
TBA
Installation procedure
1. Scanner right cover.
2. Make a screw hole in the removed scanner right cover with a screwdriver or drill.
3. Attach the tray bracket [A] to the scanner right cover ( [B] × 2: M3x10).
• For this model, use the screw holes marked "1" on the table bracket.
Key Counter Bracket Type M3
155
