Adjustment after replacing
Image position adjustment
Parts that require adjustment
The following items need to be adjusted after replacement or executing SP5-801 (Memory Clear).
• Lens block
• Scanner motor
• Polygon motor*1
• Laser unit*1
• Paper Feed Tray
• Bypass Tray
• Duplex unit
• ADF
*1
Details of Polygon motor or Laser unit: see “Laser Unit” (page 276)
Laser-related adjustment
• Make sure that paper is properly set on each paper feed tray when adjusting (adapt the paper
sizes and types to the customer’s environment). Set the value of SP2-109-003 (Test Pattern) to [14:
Trimming Area], to obtain test patterns, except for the main scan magnification adjustment. After
adjustment is completed, set the value of SP2-109-003 to [0: None].
<Standard (Margin)>
• Leading edge: 4.2±1.5mm (Plain, Thin)
• Right and Left: 0.5 to 4.0mm
• Trailing edge: 0.5 to 6.0mm (3.0 to 6.0mm for duplex)
4. Replacement and Adjustment
434
