2. Fusing shield position sensor unit [A] ( ×1, ×2)
3. Fusing shield position sensor (upper) [A], Fusing shield position sensor (lower)[B]
Fusing Shield Drive Motor
1. Fusing unit (page 340)
Fusing Unit
357
