1. Avoid areas exposed to sudden temperature changes:
1) Areas directly exposed to cool air from an air conditioner.
2) Areas directly exposed to heat from a heater.
2. Do not place the machine where it will be exposed to corrosive gases.
3. Do not install the machine at any location over 2,000 m (6,500 ft.) above sea level. (D135 for
NA can be installed only up to 2,500m (8,202 ft.))
4. Place the main machine on a strong and level base. Inclination on any side should be no more
than 5 mm (0.2").
5. Do not place the machine where it may be subjected to strong vibrations.
Machine Space Requirements
[A] Left Over 100 mm (3.9")
[B] Rear Over 100 mm (3.9")
[C] Right Over 100 mm (3.9")
[D] Front Over 750 mm (29.5")
2. Installation
50
