• * When using wireless LAN (IEEE802.11 b/g/n:2.4-GHz band), this radio product uses the 2.4-
GHz band. Check that industrial, scientific and medical devices using the same frequency bands,
such as a microwave oven and cordless telephone, are not used nearby.
• If there is interference, communication may become unstable. Check that there are no devices likely
to cause interference in the surrounding area.
Attaching the boards
1. I/F slot B [B] ( ×2) covers.
2. Attach the extended wireless LAN board to a slot ( ×2)
• Press the extended wireless LAN board firmly in, and check it is firmly connected.
• The customer should keep the I/F card slot covers which were removed.
Attaching the antenna
1. Stick the fastener provided on the antenna case.
• Stick the fastener provided on the lower half (cable side) of the case.
• It can be stuck to either side of the antenna case.
IEEE 802.11a/g/n Interface Unit Type M2
171
