M
1. Toner transport motor (M) (page 324)
2. Toner bottle drive motor (M) [A] ( ×2)
Y
1. Toner transport motor (Y) (page 324)
2. Toner bottle drive motor (Y) [A] ( ×2)
ID Chip
K
1. Toner bottle drive motor (K) (page 330)
Drive Unit
331
