2.
Board B [A] (
×4,
×1, USB×2)
Board C
1.
Operation panel arm bracket (
page 240
)
2.
Board C [A] (
×4,
×1, USB×2)
LCD Panel
1.
Operation panel arm bracket (
page 240
)
4. Replacement and Adjustment
244
245
247
