2. Attach the 2 antennas to the rear cover of the MFP.
• The two antennas must be attached at least 12 cm apart from each other.
3. Stick 8 cable stickers on the rear face of the MFP.
4. Fix the cable.
• Take care to loop it around so that it does not interfere with other options or I/F cables.
5. Switch the power supply ON.
6. Check that the system settings list is output, and the option is recognized correctly.
Settings
Check the connection of the wireless LAN interface
1. Check the IPv4 address and subnet mask, or IPv6 address setting of the MFP.
2. Press the [Default setting/counter] key.
3. Press the [System default setting] button.
4. Choose [Wireless LAN] in [Interface setting].
2. Installation
172
