Platen Cover PN2000
Accessory Check
Check that you have the accessories indicated below.
No.
Description
Q’ty
1
COVER:PRESSURE PLATE
1
2
SHEET:PRESSURE PLATE:ASS'Y
1
3
SUPPORTER:FEELER
1
4
GUIDE PIN:PRESSURE PLATE:HINGE
2
Installation Procedure
•
Unplug the machine power cord before starting the following procedure.
2. Installation
82
83
85
