Service Call 201-285
SC200 (Engine: Image Writing)
SC No. Level Error Name/Error Condition/Major Cause/Solution
SC201-00 D Polygon Motor Error
XSCRDY signal (Polygon ready) Error
• I/F harness for Polygon Motor Driver is broken/contact failure
• Polygon Motor/Polygon Motor Driver failure
• Driving pulse from Polygon Motor output abnormally (Polygon
controller area)
• Unable to monitor XSCRDY signal (Polygon controller area)
• Cycle the main power On/Off
• Replace the polygon motor
• Replace the laser unit
• Replace the I/F harness
• Replace the IPU
Service Call 201-285
457
