2. Installation
Installation Requirements
Environment
Temperature Range:
10°C to 32°C (50°F to 90°F)
Humidity Range:
15% to 80% RH
Ambient Illumination:
Less than 1,500 lux (do not expose to direct sunlight.)
Ventilation:
Room air should turn over at least 30 m3/hr/person
