Cedex Bio System 12 ISE description
Hardware
ISE tower A hollow, transparent cylinder with multiple inlets and outlets for air and solutions.
In the ISE tower, samples and diluents are mixed using an air stream.
Tubing Tubing is used for transporting the fluids. It connects the ISE unit with the water and
waste system, and also with the ISE Reference Solution and ISE Calibrator
indirect/urine bottles, which are placed on the ISE unit.
Sensors The ISE sample sensor detects the presence of liquid (sample, control, standard
solution, or ISE Calibrator indirect/urine) or air and enables the correct placing of
segments for measurement and cleaning.
The ISE Reference Solution sensor detects the presence of ISE Reference Solution.
ISE fluid bottles Two bottles are placed on the ISE unit:
o ISE Calibrator indirect/urine bottle (blue label)
o ISE Reference Solution bottle (red label)
Level monitoring is performed on the basis of weight, the bottles are placed on scales.
Fluid containers
The following table shows which container is used for which fluid:
Fluid Container(s) Position
Samples Tube Sample area
Controls Tube Sample area
ISE Solution 1 and 2 Tube Sample area
Cleaner External cleaner bottle External fluid rack
ISE Deproteinizer Tube Sample area
Activator Tube Sample area
ISE Etcher Tube Sample area
ISE Reference Solution Bottle ISE unit
ISE Calibrator indirect/urine Bottle ISE unit
Water External water container External fluid rack
Waste External waste container External fluid rack
Table E-2 Fluids, containers, and where they are used
The term tube includes all kinds of tubes, as long as their dimensions lay within prescribed
limits. It also includes secondary tubes (cups). See Tubes on page A-53.
