Roche Cedex Bio System User Manual

Roche Diagnostics
Operator’s Manual · Version 3.1 A-63
Cedex Bio System 3Hardware
Hardware overview
Connectors
A Power supply
B Data and communication connectors
C Fluid connectors
D Front USB port (not shown)
E Serial communication connector
F Barcode scanner connector
G Maintenance connectors (Do not remove the
cable.)
H USB 2 connector (for troubleshooting)
I Water connector
J Cleaner connector
K Waste connector
Figure A-32 Connectors
B
C
A
D
A
E
F
G
H
I J K
