Covers and panels
Covers and panels
The following figure shows the removable panels and the lids that can be opened.
Transfer head cover Provides access to:
o Transfer mechanism
o Probe
Shut down the system and switch off the instrument before you open this cover.
Left service flap Provides access to:
o Wash station
o Tubing
o Internal waste tank
o Initialization plate
Handle as instructed during maintenance actions, or shut down the system and
switch off the instrument before handling it.
A Left side panel
B Left service flap
C Main cover
D Transfer head cover
E Rear service flap
F Right side panel
G Right service flap
H Printer panel
Figure A-7 The Cedex Bio instrument
B C D
F
E
G
A
H
