Command in the context menu Meaning Reaction
Resume step Execution of the con‐
trol recipe is resumed
at the held step.
The "Resume step" command resumes steps
on hold (RUP, SUB, ROP). If recipe phases
have also been stopped then these phases
return to the status "Running".
Note:
Steps in the error state can be reactivated
with "Resume step".
Complete step Execution of the step
is completed.
This command terminates the recipe phase
of a step (RUP, SUB, ROP, RPH) that is non-
self-terminating (requirement: Ready status).
Stop step The processing of the
control recipe is stop‐
ped at this step.
You will find further information in the section
"Stop step (Page 1117)".
Abort step The processing of the
control recipe is abor‐
ted at this step
You will find further information in the section
"Abort step (Page 1118)".
Reset step Execution of the step
is reset
Following an abort, the unit or the equipment
modules of the step are normally still alloca‐
ted. "Reset step" cancels the allocation IDs of
all the recipe phases in the step (RUP, SUB,
ROP, RPH).
Set/remove breakpoint The breakpoint is dis‐
played as a red dot
next to the control rec‐
ipe element.
You can find additional information in the sec‐
tion "Setting breakpoints (Page 425)".
SFC visualization > Open
overview
This function opens
the overview window
of the SFC visualiza‐
tion. Double-click in
the window to display
the content.
Requirements:
● The corresponding recipe phase must be
configured as an SFC type in PCS 7
Engineering.
● The PCS 7 OS Client add-on must also be
installed on the PC in addition to an
installation of the BATCH Client.
SFC visualization > Open
pane
This function opens a
detail window of the
SFC visualization.
Requirements:
● The corresponding recipe phase must be
configured as an SFC type in PCS 7
Engineering.
● The PCS 7 OS Client add-on must also be
installed on the PC in addition to an
installation of the BATCH Client.
Comment batch element ... Add comments for the
individual batch ele‐
ments. This can be
done before, during
and after the runtime
of a batch.
-
BATCH Control Center
9.8 Batch control
SIMATIC BATCH V8.2
418 Operating Manual, 02/2016, A5E35958174-AA
