Page 4-48 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
Install the Rewind Platen Roller
Refer to Figure 4-27.
1. Insert the long end of the shaft through the hole in the main frame as far as possible.
2. Insert the short end through the roller adjust plate.
3. Install a new bearing on the roller adjust plate with the flange of the bearing on the
outside of the adjust plate. Install C-clip in the groove on the end of the roller shaft.
Slide the roller to the left to seat the bearing into the adjust plate.
4. Install a new bearing, spacer, and pulley on the long end of the platen roller.
5. Ensure that both set screws in the platen roller pulley align with the flats on the
platen roller shaft.
6. Adjust the peel roller pulley on the left side of the peel roller shaft. Leave a gap of
approximately 0.020 in. (0.5 mm) between the spacer and the pulley.
7. Tighten the set screws.
8. Reinstall and adjust the rewind drive belt.
9. Reinstall and adjust the main drive belt.
10. Reinstall the electronics cover.
11. Reinstall the media and ribbon. Close the printhead and media cover.
12. Reconnect the data cables and the AC power cord.
13. Turn the printer On (l).
14. Perform a Pause Key Self Test and observe the tracking of the rewind drive belt and
the tracking of the label liner. If you move the roller adjust plate, you must readjust.
Note • Ensure both flanged bearings are installed with the flanged side facing
out.
