13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 1-15
System Description Section 1
Parallel Port Connector
The following table shows the pin configuration and function of a standard PC-to-printer
Centronics parallel cable.
Optional Interface Boards
For information about the IBM plug-compatible Twinax Interface, the IBM plug-compatible Coax Interface, or
the RS-485 network interface, refer to the instructions that accompany the interface option.
36-Pin Connector Description
1 nStrobe/HostClk
2–9 Data Bits 1–8
10 nACK/PtrClk
11 Busy/PtrBusy
12 PError/ACKDataReq
13 Select/Xflag
14 nAutoFd/HostBusy
15 Not Used
16 and 17 Ground
18 +5 V @ 1A (110XiIIIPlus = 750 mA)
19–30 Signal Grounds
31 ninit
32 nFault/NDataAvail
33 and 34 Not Used
35
+5 V through a 4.7 KΩ
Resistor
36 NSelectIn/1284 active
Note • Optional Ethernet networking communications is available with
ZebraNet PrintServer II. Refer to the ZebraNet Networking: PrintServer II
Operating Guide (Zebra part number 45537L) when using this communications
option.
