Page 4-56 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
Remove and Install the Cutter Slotted Link
1. Refer to RRP No. 1 on page 4-14. Turn the printer Off (O), remove the AC power
cord and data cables.
2. Refer to RRP No. 2 on page 4-16 and remove the electronics cover.
3. Refer to RRP No. 3 on page 4-17 and remove the power supply.
4. Refer to Figure 4-32. Remove the E-ring securing the cutter main link to the pivot
pin in the cutter slotted link.
5. Remove the E-ring, flat washer, and bearing securing the cutter slotted link to the
pin on the lower drive arm.
6. Remove the E-ring and two flat washers securing the cutter slotted link to the pivot
post.
7. Remove the slotted link.
8. Install the new slotted link as shown in Figure 4-32.
9. Secure the slotted link to the pivot post with two flat washers and the E-ring.
10. Install the bearing onto the lower drive arm. Place the slot in the slotted link over the
bearing. Secure the link with a washer and E-ring.
11. Secure the main link to the pivot pin of the slotted link with an E-ring.
12. Apply a small amount of white lithium grease to the slot in the slotted link where the
bearing will ride. Remove any excess grease to prevent it from contaminating the
cutter optical sensor.
13. Reinstall the power supply.
14. Reinstall the electronics cover.
15. Reconnect the data cables and AC power cord.
16. Turn the printer On (l).
Caution:
Unless indicated otherwise, turn the printer Off (O) and disconnect the printer
from the power source before performing the following maintenance.
Caution:
This installation must be performed by a qualified service technician.
Caution:
Wear protective eyewear when removing E-rings, C-clips, snap rings, and
springs. All of these are under tension and could fly off while being removed.
