Zebra 110XiIII Plus Series User Manual

13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 4-97
Maintenance Section 4
Figure 4-66. Configuration Label PrintServer II
Install the Internal PrintServer II
This section provides the information necessary to install the internal PrintServer II. Read
this section completely before performing the installation procedure.
This installation should be performed by a qualified service technician, who must follow
the step-by-step procedure provided in these instructions.
After you have finished installing the PrintServer II hardware, refer to the appropriate
section of this guide for information on establishing a connection for your network type.
Caution:
The printer electronics are susceptible to static discharge. Before proceeding, it
is highly recommended that the technician wear an antistatic wrist strap
connected to the printer chassis.
Note • The parallel port on the back of the printer is not operational when the
internal PrintServer II is installed. The hardware of the PrintServer II mounting
bracket covers the parallel port.
