Page 2-44 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 2 Operations Overview
Set Head Resistance Value
This value has been preset at the factory to match the resistance value of the printhead. It
must not be changed unless the printhead is replaced.
Before replacing a printhead, look on the bottom of the new printhead for the label that
shows the resistance (ohm = Ω) value.
Press the left oval key to move to the next digit position, and press the right oval key to
increase the value of the digit.
Press NEXT/SAVE to display VERIFIER PORT.
Set Verifier Port
The auxiliary port determines how the printer reacts to the online verifier. There are three
operating conditions for this port:
1. Off: The verifier port is off.
2. VER-RPRNT ERR: Label reprinted if verifier detects an error. If a bar code is near
the upper edge of the label, the label is fed out far enough to be verified then
backfeed to allow the next label to be printed and verified.
3. VER-THRUPUT: Allows greatest throughput but may not indicate a verification
error immediately upon detection. May print from one to three labels before an error
is recognized and printing stops.
For more information on the operation of the optional verifier, refer to the documentation
provided with that option.
Press NEXT/SAVE to display APPLICATOR PORT.
Caution:
Do not set the value higher than that shown on the printhead. Setting the value to
a higher number can damage the printhead.
Initial Value: Factory set
Range: 0488–2415
HEAD RESISTOR
092 OHMS +1
Default: Off
Range: Off, 1 VER-RPRNT, 2 VER-THRUPUT
VERIFIER PORT
OFF
