Page 4-128 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 4 Maintenance
Wireless PCMCIA and PCMCIA Option Board Assemblies
Access the Printer
1. Refer to RRP No. 1 on page 4-14. Turn the printer Off (O) and remove the power
cord. Disconnect the printer communications cable.
2. Refer to RRP No. 2 on page 4-16 and remove the electronics cover.
Removing the Existing PCMCIA or Wireless PCMCIA Option Board
Assemblies
1. Refer to Figure 4-9 on page 4-19.
Remove the option card (if installed) from the card
slot located at the rear of the printer.
The Xi
IIIPlus has used two different means of securing the PCMCIA board to the main logic
board (MLB).
PCMCIA Standoffs
Refer to Figure 4-89.
1. Two plastic locking standoffs:
Remove the screw securing the PCMCIA/wireless board to a metal standoff on the printer
chassis.
a. Remove the screw securing the PCMCIA/wireless board to a metal standoff on the
printer chassis.
b. Disconnect the PCMCIA/wireless board from two plastic standoffs.
c. Gently pull the PCMCIA/wireless board away from the MLB to disconnect the two
connectors, P24 and P23, on the MLB.
d. Replace the two plastic locking standoffs with two screws, spacers, and nuts. Refer to
Figure 5-5 on page 5-15 and Table 5-5 on page 5-14.
e. To install the new hardware, refer to Figure 4-90.
Caution:
Unless indicated otherwise, turn the printer Off (O) and disconnect the printer
from the power source before performing the following maintenance.
Caution:
This installation must be performed by a qualified service technician.
Caution:
The printer electronics are susceptible to static discharge. Before proceeding, it
is highly recommended that the technician wear an antistatic wrist strap
connected to the printer chassis.
