Page 5-4 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-1. Final Assembly Mechanical
Item Part Number Description Qty
1 46937 Media Door with Window 1
1 47077M Media Door Kit, Bi-fold with Window 1
2 HW30392-004 Screw, 6-32 × 0.25, Phillips head (only available in quantities of 50) 10
3 47098 Media Load Label 1
4 01861 Supplies Label 1
5 46396-006 Screw, 6-32 × 0.37, Phillips head 2
6 30407-008 Screw, 6-32 × 0.5, 3/64 Allen 4
7 HW44114 Screw, M4.2 × 8 Hilo (only available in quantities of 50) 10
8 HW44356 Washer, 0.198, 0.75 0.085 (only available in quantities of 25) 2
9 32036M PCB Panel Maintenance Kit 1
10 41021M Media Cover Maintenance Kit 1
11 41002 Name Plate 1
12 22021 Membrane Switch 1
13 22492M Panel with Membrane Switch Maintenance Kit 1
14 33036-5 Front Cover 1
15 32043M LCD, Back Light Maintenance Kit 1
16 01130 Nut, 6-32 3
17 HW01152 Washer (only available in quantities of 25) 3
18 41003 Lower Media Trim Panel 1
19
HW30256-B Thumb Nut, 6-32 × 0.50 Brass (only available in quantities of 25) 2
20
41042 Front Cover Bracket 1
21 41049 Support Bracket 1
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
