13185L-002 Rev. A 1/24/06 110XiIIIPlus Maintenance Manual Page 1-5
System Description Section 1
Figure 1-1. Default Font Examples
Table 1-3. Font Matrix for 24 dot/mm (600 dpi) Printheads
Font Matrix Type* Character Size
Height Width
Baseline
Dots
Inter-Character
Gap
Cell
Width
Font Matrix
Inches Millimeters
Height Width
Char/
Inch
Height Width
Char/
mm
A 9 5 7 1 6 U-L-D 0.015 0.010 100.00 0.38 0.25 3.94
B 11 7 11 2 9 U 0.018 0.015 66.70 0.45 0.38 2.62
C, D 18 10 14 2 12 U-L-D 0.030 0.020 50.00 0.76 0.51 1.96
E 82 40 64 6 26 OCR-B 0.137 0.087 11.54 3.47 2.20 0.45
F 26 13 21 3 16 U-L-D 0.043 0.027 37.50 1.10 0.69 1.48
G 60 40 48 8 48 U-L-D 0.100 0.080 12.50 1.25 1.10 0.50
H 60 38 30 9 28 OCR-A 0.100 0.093 10.71 2.50 2.40 0.42
GS 24 24 24 2 26 Symbol 0.040 0.040 25.00 1.00 2.10 0.90
P 20 18 N/A N/A N/A U-L-D 0.067 0.060 N/A 1.69 1.52 N/A
Q 28 24 N/A N/A N/A U-L-D 0.093 0.080 N/A 2.37 2.03 N/A
R 35 31 N/A N/A N/A U-L-D 0.117 0.103 N/A 2.96 2.62 N/A
S 40 35 N/A N/A N/A U-L-D 0.133 0.117 N/A 3.39 2.96 N/A
T 48 42 N/A N/A N/A U-L-D 0.160 0.140 N/A 4.06 3.56 N/A
U 59 53 N/A N/A N/A U-L-D 0.197 0.177 N/A 5.00 4.49 N/A
V 80 71 N/A N/A N/A U-L-D 0.267 0.237 N/A 6.77 6.01 N/A
*U = Uppercase, L = Lowercase, D = Descenders
FONT V--
ABCD
12345
wxyz
ABCD
ABCD
ABCD
ABCD
ABCD
ABCD
12345
12345
12345
12345
12345
12345
12345
ABCD
(Scalable)
wxyz
wxyz
wxyz
wxyz
wxyz
wxyz
wxyz
FONT U--
FONT T--
FONT S--
FONT R--
FONT Q--
FONT P--
FONT GS
FONT 0
FONT
G
Az 4
--
--
--
FONT E -- (OCR-B) ABCDwxyz 12345
FONT
FONT
FONT
FONT
F --
D --
B --
A --
ABCD
ABCD
ABCD
ABCD
12345
12345
12345
12345
wxyz
wxyz
WXYZ
wxyz
FONT H -- (OCR-A) UPPER CASE ONLY
CR
