Page 5-28 110XiIIIPlus Maintenance Manual 13185L-002 Rev. A 1/24/06
Section 5 Maintenance and Assembly Drawings
Table 5-13. Cutter Option Assembly (View 1)
Item Part Number Description Qty
1 HW02133 E-Ring, 0.188 Black (only available in quantities of 50) 4
2 30199 Bearing, 0.375 × 0.189 × 0.125 3
3 30214 Main Link 1
4 Q10019 E-ring, 0.250 Black 1
5 30210 Flat Washer, 0.564 × 0.384 × 0.060 2
6
30217-1
Link Pin, 0.187 Dia. 1
7 HW30208 Flat Washer, 0.500 × 0.191 × 0.030 (only available in quantities of 25) 2
8 30215 Slotted Link 1
9 30198 Bearing 0.500 × 0.252 × 0.250 1
10 30133 Ball Bearing 0.375 × 0.187 × 0.125 1
11 31313 Cutter Opto Wire Clamp 1
12 01822 Nut, 4–40 5
13 40380M Lower Drive Arm Maintenance Kit 1
14 30219 Flag, Sensor 1
15 HW01155 Washer, Lock #4 (only available in quantities of 100) 1
16 30236 Screw 4-40 × 0.25 3
17 30216 Post, Pivot 1
18 46618 Cutter Sensor 1
19 30394-005 Screw, 10-32 × 0.312 2
20 30382RM Cutter Plate Maintenance Kit 1
21 30405-006 Screw, ¼–20 × 0.38 1
22 HW44632 Ferrite Ring 1.1 × 0.75 (only available in quantities of 10) 1
23 46224 Rubber Grommet 1
24 08449 Cable-Tie, 0.187 W × 11.5 L 1
25 30374M Cutter Motor Maintenance Kit 1
26 HW30391-003 Screw, 4–40 × 0.19 (only available in quantities of 25) 4
27 49604-012 Power Distribution Cable 1
28 49600-012 Comm. Cable 1
29 49730M Cutter Control PCB Maintenance Kit 1
30 46280M Arm Drive Upper Maintenance Kit 1
31 30816 Lower Cutter Bracket 1
32 HW40193 Flat Washer, 0.406 × 0.172 × 0.048 (only available in quantities of 25) 2
33 HW30392-004 Screw, 6–32 × 0.25 (only available in quantities of 50) 4
Bold=Part available for purchase
Italic=Part not available for purchase, listed and shown for reference only
