Preface
Access the Attachments
The Microsoft Excel spreadsheet that is attached to this publication contains
fault code descriptions. To use the spreadsheet file, click the Attachments link
, right-click the spreadsheet file, and save the file to your computer.
If the PDF file opens in a browser and you don't see the Attachments link ,
download the PDF file and reopen the file with the Adobe Acrobat Reader
application.
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
Table 2 - Additional Resources
Resource Description
Kinetix Rotary Motion Specifications Technical Data, publication KNX-TD001
Provides product specifications for Kinetix VP (Bulletin VPL, VPC, VPF, and VPS),
MP-Seriesâ„¢ (Bulletin MPL, MPM, MPF, and MPS), and HPK-Seriesâ„¢ rotary motors.
Kinetix Linear Motion Specifications Technical Data, publication KNX-TD002
Provides product specifications for Bulletin MPAS and MPMA linear stages,
Bulletin VPAR, MPAR, and MPAI electric cylinders, LDAT-Series linear thrusters, and
LDC-Seriesâ„¢ linear motors.
Kinetix Servo Drives Specifications Technical Data, publication KNX-TD003
Provides product specifications for Kinetix Integrated Motion over the EtherNet/IP
network, Integrated Motion over sercos interface, EtherNet/IP networking, and
component servo drive families.
Kinetix Motion Accessories Specifications Technical Data, publication KNX-TD004
Provides product specifications for Bulletin 2090 motor and interface cables, low-
profile connector kits, drive power components, and other servo drive accessory
items.
AC Line Filter Installation Instructions, publication 2198-IN003
Provides information on installing and wiring the Kinetix 5500 and Kinetix 5700 AC
line filters.
Kinetix 5700 Regenerative Bus Supply Installation Instructions, publication 2198-IN014
Provides information on installing and wiring the Kinetix 5700 regenerative bus
supply.
Kinetix 5700 Capacitor Modules Installation Instructions, publication 2198-IN008 Provides information on installing and wiring the Kinetix 5700 capacitor modules.
Replacement Fan Kit Installation Instructions, publication 2198-IN015
Provides information on removal and replacement of cooling fans used in 2198-
RPxxx regenerative bus supplies and 2198-S263-ERSx and 2198-S312-ERSx single-
axis inverters.
Kinetix 5700 DC-bus Conditioner Module Installation Instructions, publication 2198-IN016
Provides information on installing and wiring the Kinetix 5700 DC-bus conditioner
module.
Kinetix 5700 Shunt Passive Modules Installation Instructions, publication 2198-IN011 Provides information on installing and wiring Kinetix 5700 passive shunts.
Kinetix 5700 Safe Monitor Functions Safety Reference Manual, publication 2198-RM001
Provides a description of integrated stopping functions and safe monitoring
functions with a GuardLogix® controller and Kinetix 5700 servo drives.
iTRAK System User Manual, publication 2198T-UM001
Provides information on installing the Kinetix 5700 iTRAK power supply with an
iTRAK system and programming the iTRAK system.
