Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 295
Chapter 8
Remove and Replace Drive Modules
This chapter provides remove and replace procedures for Kinetix® 5700 drive
modules.
Before You Begin
When each drive module is installed, network settings are configured from the
setup screens. Before removing the module, revisit the Network menu and
make note of the static IP or DHCP settings. Refer to Configure the Drive
on
page 198
to access those settings.
You also need these tools available before you begin removal and replacement
procedures:
• Screwdrivers (to loosen/remove screws)
• Voltmeter (to make sure that no voltage exists on drive connectors)
Topic Page
Before You Begin 295
Remove and Replace Kinetix 5700 Drive Modules 296
Start and Configure the Drive Module 302
ATTENTION: This drive contains electrostatic discharge (ESD) sensitive parts
and assemblies. You are required to follow static-control precautions when
you install, test, service, or repair this assembly. If you do not follow ESD
control procedures, components can be damaged. If you are not familiar
with static control procedures, refer to Guarding Against Electrostatic
Damage, publication 8000-4.5.2
, or any other applicable ESD awareness
handbook.
IMPORTANT If you intend to use the same Logix Designer application after replacing
your drive module, the new module must be the same catalog number as
the old module.
