Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 199
Configure and Start the Kinetix 5700 Drive System Chapter 6
Table 110 - AOP Installation Requirement
Install the Kinetix 5700 Add-On Profile
Download Add-On profiles (AOP) from the Product Compatibility
Download Center (PCDC) website:
http://compatibility.rockwellautomation.com/Pages/home.aspx
.
Follow these steps to download the Kinetix 5700 Add-On profile.
1. Go to the Product Compatibility Download Center.
The Compatibility & Downloads webpage appears.
2. Enter Kinetix 5700 in the Search PCDC window.
3. Click the appropriate firmware revision and follow prompts to
download.
4. Extract the AOP zip file and run Setup.
Drive Cat. No. Drive Firmware Revision
Logix Designer
Application Version
Kinetix 5700
AOP Needed?
2198-xxxx-ERS3 (series A)
4.001
26.00 or 27.00 Yes
28.00 or later No
5.001
26.00, 27.00, 28.00 Yes
29.00 or later No
7.001 or later
(1)
(1) Drive firmware 7.001 enhancements are available only with the Studio 5000 Logix Designer, version 29.00 or later, firmware
update. The AOP for firmware 7.001 is not available for download.
29.00 or later No
2198-xxxx-ERS3 (series B)
2198-xxxx-ERS4
9.001 or later
(2)
(2) Drive firmware 9.001 enhancements are available only with the Studio 5000 Logix Designer, version 31.00 or later, firmware
update. The AOP for firmware 9.001 is not available for download.
31.00 or later No
10.001 or later
(3)
(3) Drive firmware 10.001 enhancements are available only with the Studio 5000 Logix Designer, version 32.00 or later, firmware
update. The AOP for firmware 10.001 is not available for download.
32.00 or later No
