Appendix D Maximum Motor Cable Lengths for Kinetix 5700 Power Supplies
Regenerative Bus Supply
Configurations
2198-RPxxx regenerative bus supplies have limited maximum drive-to-motor
cable length when DC-bus regulation is enabled. However, the DC Bus can be
extended up to 70 m (230 ft) to remote clusters of Kinetix 5700 inverters. The
result is a shorter distance from the inverter to the motor and thus shorter
individual motor cable lengths.
Table 182 - Regenerative Bus Supply (480V AC input)
Table 183 - Regenerative Bus Supply (400V AC input)
AC Input Power Source Type
(1)
Motor/Actuator Cat. No.
Drive-to-Motor Cable Length, max
m (ft)
With DC-bus
Conditioner
Without DC-bus Conditioner
WYE Grounded
•LDAT-Sxxxxxx
•LDC-Cxxxxxx
•MPAS-B8xxxF-ALM
•MPAS-B9xxxL-ALM
10 (32.8) 10 (32.8)
•VPx-B063xx, VPx-B075xx
•MPx-B15xx, MPx-B2xx
•VPAR-B1xxxx, VPAR-B2xxxx
•MPAR-B1xxxx, MPAR-B2xxxx
•MPAS-Bxxxx1, MPAS-Bxxxx2
•MPAI-Bxxxxx
20 (65.6) 15 (49.2)
•VPx-B100xx…VPx-B300xx
•VPAR-B3xxxx
•MPAR-B3xxxx
•RDB-Bxxxxx
•MPx-B3xxx…MPx-B9xxx
• MPM-B115xx…MPM-B215xx
•HPK-xxxxxx
50 (164) 30 (98.4)
WYE Impedance Grounded
(2)
•LDAT-Sxxxxxx
•LDC-Cxxxxxx
•MPAS-B8xxxF-ALM
•MPAS-B9xxxL-ALM
10 (32.8) 10 (32.8)
•VPx-B063xx, VPx-B075xx
•MPx-B15xx, MPx-B2xx
•VPAR-B1xxxx, VPAR-B2xxxx
•MPAR-B1xxxx, MPAR-B2xxxx
•MPAS-Bxxxx1, MPAS-Bxxxx2
•MPAI-Bxxxxx
20 (65.6) 15 (49.2)
•VPx-B100xx…VPx-B300xx
•VPAR-B3xxxx
•MPAR-B3xxxx
•RDB-Bxxxxx
•MPx-B3xxx…MPx-B9xxx
• MPM-B115xx…MPM-B215xx
•HPK-xxxxxx
50 (164) 30 (98.4)
(1) Corner-grounded and ungrounded input power can be used, but you must add an isolation transformer to the input power circuit to provide grounded-WYE power. Unbalanced, floating, or
ungrounded systems can cause additional stress to the motor. For more information on these input power source types, see Input Power Configurations for Kinetix 5700 Power Supplies
on page 129.
(2) Impedance grounded systems running in ground fault conditions, for prolonged periods of time, cause additional stress to the motor insulation and can cause premature motor failure.
AC Input Power Source Type
(1)
Motor/Actuator Cat. No.
Drive-to-Motor Cable Length, max
m (ft)
With DC-bus
Conditioner
Without DC-bus Conditioner
WYE Grounded
•LDAT-Sxxxxxx
•LDC-Cxxxxxx
•MPAS-B8xxxF-ALM
•MPAS-B9xxxL-ALM
10 (32.8) 10 (32.8)
•VPx-B063xx, VPx-B075xx
•MPx-B15xx, MPx-B2xx
•VPAR-B1xxxx, VPAR-B2xxxx
•MPAR-B1xxxx, MPAR-B2xxxx
•MPAS-Bxxxx1, MPAS-Bxxxx2
•MPAI-Bxxxxx
50 (164) 30 (98.4)
•VPx-B100xx…VPx-B300xx
•VPAR-B3xxxx
•MPAR-B3xxxx
•RDB-Bxxxxx
•MPx-B3xxx…MPx-B9xxx
•MPM-B115xx…MPM-B215xx
•HPK-xxxxxx
90 (295) 90 (295)
WYE Impedance Grounded
(2)
•LDAT-Sxxxxxx
•LDC-Cxxxxxx
•MPAS-B8xxxF-ALM
•MPAS-B9xxxL-ALM
10 (32.8) 10 (32.8)
•VPx-B063xx, VPx-B075xx
•MPx-B15xx, MPx-B2xx
•VPAR-B1xxxx, VPAR-B2xxxx
•MPAR-B1xxxx, MPAR-B2xxxx
•MPAS-Bxxxx1, MPAS-Bxxxx2
•MPAI-Bxxxxx
50 (164) 30 (98.4)
•VPx-B100xx…VPx-B300xx
•VPAR-B3xxxx
•MPAR-B3xxxx
•RDB-Bxxxxx
•MPx-B3xxx…MPx-B9xxx
•MPM-B115xx…MPM-B215xx
•HPK-xxxxxx
90 (295) 90 (295)
(1) Corner-grounded and ungrounded input power can be used, but you must add an isolation transformer to the input power circuit to provide grounded-WYE power. Unbalanced, floating, or
ungrounded systems can cause additional stress to the motor. For more information on these input power source types, see Input Power Configurations for Kinetix 5700 Power Supplies
on page 129.
(2) Impedance grounded systems running in ground fault conditions, for prolonged periods of time, cause additional stress to the motor insulation and can cause premature motor failure.
