Chapter 2 Plan the Kinetix 5700 Drive System Installation

Circuit Breaker/Fuse Selection

The Kinetix 5700 power supplies use internal solid-state motor short-circuit

protection and, when protected by suitable branch circuit protection, are rated

for use on a circuit capable of delivering up to 200,000 A (fuses) and 65,000 A

(circuit breakers).

Refer to Power Wiring Examples

, on page 343, for the wiring diagram.

Table 9 - DC-bus Power Supply UL/CSA Circuit-protection Specifications

Table 10 - Regenerative Bus Supply UL/CSA Circuit-protection Specifications

Table 11 - DC-bus Power Supply IEC (non-UL/CSA) Circuit-protection Specifications

ATTENTION: Do not use circuit protection devices on the output of an AC

drive as an isolating disconnect switch or motor overload device. These

devices are designed to operate on sine wave voltage and the drive’s PWM

waveform does not allow it to operate properly. As a result, damage to the

device occurs.

DC-bus Power Supply

Cat. No.

Input Voltage

(three-phase) nom

Bussmann Fuses

(1)

Cat. No.

Miniature CB

(2)

Cat. No.

Motor Protection CB,

(2)

Self Protected CMC

Cat. No.

Molded Case CB

Cat. No.

2198-P031

324…528V AC

LPJ-15SP (15A) 1489-M3D250 140M-D8E-C25 140G-G6C3-C25

2198-P070 LPJ-40SP (40A) N/A 140M-F8E-C45 140G-G6C3-C50

2198-P141 LPJ-70SP (70A) N/A N/A 140G-G6C3-C90

2198-P208 LPJ-100SP (100A) N/A N/A 140G-G6C3-D12

(1) For applications requiring CSA certification, fuses (Bussmann catalog number 170M1760) must be added to the DC link between the two drive clusters when circuit breakers are used for branch circuit

protection. The DC bus fuses are not required when AC line fuses are used for branch circuit protection.

(2) These Bulletin 140M circuit breakers, when used as self-protected (Type E) devices, and Bulletin 1489 circuit breakers can be used on only WYE power systems (480Y/277V).

Regenerative Bus Supply

Cat. No.

Input Voltage

(1)

(three-phase) nom

Bussmann Fuses

(2)

Cat. No.

Mersen Fuses

Cat. No.

Miniature CB

Cat. No.

Molded Case CB

Cat. No.

2198-RP088

324…506V AC rms

LPJ-45SP (45A) AJT45 (45A) – 140G-G6C3-C60

2198-RP200 LPJ-125SP (125A) AJT125 (125A) – 140G-J6F3-D15

2198-RP263 LPJ-200SP (200A) AJT200 (200A) – 140G-K6F3-D30

2198-RP312 LPJ-250SP (250A) AJT250 (250A) – 140G-K6F3-D40

(1) Applies when DC-bus voltage regulation is enabled. If DC-bus voltage regulation is not enabled, then the input voltage range is 324….528V AC. For more information on these two modes of

operation, see DC-bus Voltage Regulation

on page 42.

(2) For applications requiring CSA certification, fuses (Bussmann catalog number 170M1760) must be added to the DC link between the two drive clusters when circuit breakers are used for branch circuit

protection. The DC bus fuses are not required when AC line fuses are used for branch circuit protection.

DC-bus Power Supply

Cat. No.

Drive Voltage

(three-phase) nom

DIN gG Fuses

Amps, max

Miniature CB

Cat. No.

Motor Protection CB

Cat. No.

Molded Case CB
