Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 183
Connect the Kinetix 5700 Drive System Chapter 5
External Active-shunt
Connections
Active shunts are available from the Rockwell Automation Encompassâ„¢ partner
Powerohm Resistors, Inc. See Active Shunt Considerations
on page 52 for
Powerohm shunts compatible with your Kinetix 5700 power supply.
Follow these guidelines when wiring your Powerohm active shunt:
•Refer to External Active Shunt Modules
on page 76 for noise zone
considerations.
•Refer to Active Shunt Wiring Examples
on page 360.
• Refer to the installation instructions provided with your Bulletin
PWBxxx and PKBxxx Powerohm shunt module.
DC-bus Power Supply Active Shunt Connections
Make active shunt connections in drive systems that include the
DC-bus power supply and Powerohm PKBxxx or PWBxxx active shunts at the
external DC-bus studs on accessory modules.
Refer to Wire the External DC-bus Connections
on page 184.
Regenerative Bus Supply Active Shunt Connections
Make active shunt connections to the 2198-RPxxx regenerative bus supply at
the active shunt (RC) connector or the external DC-bus studs on accessory
modules, depending on the shunt type.
Rockwell Automation Encompass Partners Contact Information
Powerohm Resistors, Inc.
5713 13th Street
Katy, Texas 77493
Tel: (800) 838-4694
http://www.powerohm.com
IMPORTANT To improve system performance, run wires and cables in the wireways as
established in Chapter
2.
