192 Rockwell Automation Publication 2198-UM002G-EN-P - February 2019
Chapter 6 Configure and Start the Kinetix 5700 Drive System
Table 104 - Navigating the iTRAK Power Supply Menu
Setup Screens
The setup screens provide the means of changing drive settings, for example,
the IP address. Press one of the setup buttons to access the setup screens.
You can use the soft menu items and navigation buttons to
view the information and make changes.
Press to validate your changes:
• If the change is invalid, the value doesn’t change.
• If the change is valid, an asterisk appears next to the
changed attribute.
Menu/Sub Menu
Selections
Attributes Description Example Values
Module Info
Catalog number 2198T-W25K-ER
Firmware revision FW: 6.1.7100254
Hardware revision HW REV: 1.1
Serial number SERIAL#: xxxxxxxxxxx
Diagnostics>
Converter
Diagnostics
Bus diagnostics BUS VOLT: 0.0V
Output 1 diagnostics
OUT1 VOLT: 0.0V
OUT1 AMPS: 0.0A
OUT1 PWR: 0.0kW
OUT1 UTIL: 0.0%
Output 2 diagnostics
OUT2 VOLT: 0.0V
OUT2 AMPS: 0.0A
OUT2 PWR: 0.0kW
OUT2 UTIL: 0.0%
Converter diagnostics TOTAL PWR: 0.0kW
Fault Log
Fault text Fault code as listed in Fault Codes
on page 277. FLT S38 - FUSE BLOWN
Fault details The problem as reported in Fault Codes on page 277 The internal DC-bus power fuse is blown
Fault help The Possible Solution as reported in Fault Codes on page 277. Return drive for repair if fault continues
IMPORTANT You must cycle control power to make network configuration changes
persistent. In this example, the IP address was changed. The change
takes affect and the asterisk disappears after control power is cycled.
Display configuration changes take effect immediately.
STATIC IP
SUBNET MASK
IP ADDRESS*
