Plan the Kinetix 5700 Drive System Installation Chapter 2
Table 24 - iTRAK Power Supply
Table 25 - Capacitor Module or DC-bus Conditioner Module
Table 26 - Extension Module
Noise Reduction Guidelines for Drive System Accessories
Refer to this section when mounting an AC (EMC) line filter or external shunt
resistor for guidelines designed to reduce system failures caused by excessive
electrical noise.
AC Line Filters
Observe these guidelines when mounting your AC (EMC) line filter (refer to
the figure on page 70
for an example):
• If your facility has grounded WYE power distribution, as shown in
Figure 80
on page 129, mount the AC line filter on the same panel as the
Kinetix 5700 power supply and as close to the power supply as possible.
• Good HF bonding to the panel is critical. For painted panels, refer to
the examples on page 68
.
• Segregate input and output wiring as far apart as possible.
Wire/Cable Connector
Zone Method
Very Dirty Dirty Clean Ferrite Sleeve Shielded Cable
DC-/DC+ (DC bus) DC Bus-bar only, no wiring connector.
iTRAK DC-bus output A and B IDC – X – – X
24V DC control input power CP
–X–– X
iTRAK 24V DC control output power A and B ICP
iTRAK digital inputs IOD – – X – –
iTRAK ready output IR – – X – –
Ethernet (shielded cable)
PORT1
PORT2
––X– X
Wire/Cable Connector
Zone Method
Very Dirty Dirty Clean Ferrite Sleeve Shielded Cable
DC-/DC+ (DC bus) DC Bus-bar only, no wiring connector.
DC-/DC+ M8 Stud – X – – –
24V DC CP – X – – –
Module status MS – X – – –
Wire/Cable Connector
Zone Method
Very Dirty Dirty Clean Ferrite Sleeve Shielded Cable
DC-/DC+ (DC bus) DC Bus-bar only, no wiring connector.
DC-/DC+ M8 Stud – X – – –
