Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 41
Chapter 2
Plan the Kinetix 5700 Drive System Installation
This chapter describes system installation guidelines used in preparation for
mounting your Kinetix® 5700 drive system components.
System Design Guidelines
Use the information in this section when planning to mount your system
components on the panel.
For on-line product selection and system configuration tools, including
AutoCAD (DXF) drawings of the product, refer to
https://www.rockwellautomation.com/global/support/selection.page
.
System Mounting Requirements
• To comply with UL and CE requirements, the Kinetix 5700 drive
system must be mounted in a grounded conductive enclosure offering
protection as defined in standard IEC 60529 to IP20 such that they are
not accessible to an operator or unskilled person.
To maintain the functional safety rating of the Kinetix 5700 drive
system, this enclosure must be appropriate for the environmental
conditions of the industrial location and provide a protection class of
IP54 or higher.
• The panel you install inside the enclosure for mounting your system
components must be on a flat, rigid, vertical surface that won’t be
subjected to shock, vibration, moisture, oil mist, dust, or corrosive
vapors in accordance with pollution degree 2 (EN 61800-5-1) because
the product is rated to protection class IP20 (EN 60529).
Topic Page
System Design Guidelines 41
Accessory Module Selection 59
Electrical Noise Reduction 67
ATTENTION: Plan the installation of your system so that you can perform all
cutting, drilling, tapping, and welding with the system removed from the
enclosure. Because the system is of the open type construction, be careful to
keep metal debris from falling into it. Metal debris or other foreign matter
can become lodged in the circuitry and result in damage to the components.
